The Concrete Kibble has been designed for easy transfer of concrete on site by overhead crane. Easy to use, easy to install and high safety. This lightweight kibble can be used for both bottom discharge or side discharge with the use of the adjustable chute. This unit is lever operated from either side, allowing flexible operation. Complete with forklift pockets for transportation about the work site. Mainly used for the transportation and dumping of concrete in construction site and bridge pier pouring site.
- Light weight, yet heavy duty
- Adjustable chute allows discharge from the bottom or side of unit
- Lever operated from either side, for flexibility of use
- Fitted with fork pockets for transport around the work site
- Hydraulic Kibble Option available on request to remotely control kibble
- Surface treatment: painted ‘Safety Yellow” enamel
| Type | Capacity | SWL | Filling Height | Transport Dimensions | Unit Weight |
| (kg) | (mm) | (kg) | |||
| CKM05 | 0.5 cu,M | 1500 | 1175 | 1400x1260x1510H | 260 |
| CKM10 | 1.0 cu,M | 3000 | 1295 | 1450x1540x1680H | 320 |
| BGK10 | 1.0 cu,M | 3000 | 1180 | 1450x1450x1865H | 273 |
| CKM15 | 1.5 cu,M | 4000 | 1366 | 1550x1550x1974H | 423 |
